Description
UltraSoniX is a high-performance couplant, available in medium viscosity, ideal for spreading.
10°F to 220°F (-12°C to 104°C) temperature range for most flaw detection and thickness gauging applications.
Water-soluble: easy to remove Environment and operator-friendly – no formaldehyde, nitrates, nitrites, or glycol ethers.
Lower residue than most UT couplants.
FAA Advisory Circular AC 25-29 which states: Procedures need to ensure glycerin is not used on aluminum materials, as it may cause corrosion.
No glycerin as required for carbon fiber composites.
Removal: Wipe with wet or dry paper or cloth rag or water wash.
| Operating Range | 10°F to 220°F (-12°C to 104°C) |
|---|---|
| Viscosity | Medium viscosity |
| Halogens and Sulfur | Less than 50 ppm |
| pH | 8.0 nominal at 20°C |
| Compliance | ASME Boiler & Pressure Vessel Code (T-533), ASTM F519, Conforms to FAA Circular Advisory AC No: 25-29, NAVSHIPS 250 – 1500, Nuclear grade (less than 50 ppm Halogens & Sulfur) |
| Packaging |
|
For more information, click here for the manufacturers product data sheet.
